Short Preview: MCU controlled 2-Channel 24 RGB-LED VU-Meter with different pattern (details inside)
Автор: andymanone
Загружено: 2016-08-31
Просмотров: 19758
Описание:
In this video you can see a small (but very cool :)) Dual Channel 24 LED VU level indicator meter.
It´s easy powered by 5V (max. 250mA, generally less than 100mA!) (how you can see, I´ve powered it by an USB Hub :))
The special thing about it is, that each of all 48 LEDs are RGB-LEDs (all of them MCU-controlled).
So you are able to play a couple of different and complex Audio-controlled Patterns.
The video shows a first, quick preview test, sorry for lack of quality :(...
To adjust the VU-Meter output values, there you´ll find two buttons on it (e.g for change the brightness, Inputlevel, Patternsequence and more).
The very inexpensive VU-indicator is available (and ready assembled!) for round about 7€ incl. shipping.
If you want to grab one of them, choose your prefered dealer or buy it here, if you want :)
http://www.ebay.de/itm/RGB-MCU-Adjust...
Or here:
http://www.ebay.de/itm/142159865167?_...
If any question , feel free to ask me...
CREDITS:
The Audiotrack is from:
Cerf, Mitiska & Jaren with Pulser - Our Little Secret
• Cerf, Mitiska & Jaren with Pulser - Our Li...
