Another Test Flight of my VTOL T1 Ranger on inav 8.0.1 and Walksnail Firmware 39.44.4
Автор: Ricky Gode
Загружено: 2025-09-27
Просмотров: 401
Описание:
Another Quick Test Flight of my VTOL T1 Ranger.
1) I reduced the auto launch throttle from 80% to 75% and it seems to be fine.
2) I adjusted the board level, but I couldn't find where I usually do it and added some forward lean in the adjustment tool tab. That way when the plane is level on the ground, it's level in inav. (this also seemed to help auto launch as it didn't climb at a 65° angle like last time)
3) I added 3 seconds of "Slow Up" and "Slow Down" in my radio so that when I flip my VTOL switch it stays in the "Transition Mode" for about a second instead of immediately going to VTOL Mode.
4) I updated EdgeTX to v2.11.3
5) I updated ELRS to v3.6.0
6) I updated my Walksnail vTx and Goggles X to v39.44.4
7) I updated my Walksnail Goggles X Internal Headtracking Module to v2.2
AUW: 790g
FC: SpeedyBee F405 Wing Mini (inav 8.0.1)
ESC: T1 VTOL FX-25A on BlueJay v0.19.2 at 48KHz
GPS: Matek M10Q-5883 GNSS & Compass
Motors: FX1806-2000KV Brushless Motor
Props: Gemfan 5126
vTx: Walksnail Avatar HD Nano Kit V3 (v38.43.13) 500mW 1080p
vRx: Walksnail Goggles X (v39.44.4) Headtracker (v2.2)
Camera: Avatar HD Pro Camera 19x19mm
Gimbal: XF C-20 3 axis (caddx GM3) firmware: v3.6
Bitrate: Standard
Frame Rate: High
Antenna: VAS 5.8GHz Minion Pro (u.fl)
Battery: 4S Lion Molicel P28A 18650 2800mAh 35A pack
Tx: RadioMaster TX16S (v2.11.3)
Rx: RadioMaster 2.4GHz RP1 ELRS (v3.6.0)
