Line Magnetic LM-211IA El34*4 Integrated Vacuum Tube Amplifier Push-pull Amplifier 32W*2
Автор: Line Magnetic official
Загружено: 2024-10-30
Просмотров: 943
Описание:
Used tubes: EL34*4, 12AX7*2, 12AU7*2
The front stage use two of 12AX7 and two of 12AU7 tubes, the rear stage use four of EL34 tubes to do class AB push-pull power amplification.
Hand made construction with finest point to point wiring.
Come with Infrared remote control and tube cover
Each tube is tested, aged, and paired before being used on the amplifier.
Power-on mute delay function (about 30 seconds)
Product Parameter:
Harmonic distortion: 1% (1Hz)
Signal to noise ratio: 88dB
Input Sensitivity: 200mV
Frequency response: 10Hz ~ 50kHz (-1.5dB)
Rated output power: 15W + 15W (RMS triode working state)
32W + 32W (RMS super-linear working state)
Input Impedance: 100kΩ
Output impedance: 4Ω, 8Ω
Supply voltage: ~ 115V/120V/220V/230V/240V ± 5% (50Hz/60Hz)
Power consumption: 220W
Net weight: 19.6Kg
Dimension: (W × D × H): (376 x 345x 191.5) mm³
