Noise Performance Comparison Of Different Linear Regulators LM7805 LM317 TLV1117 LP2985 Altium PCB
Автор: Dan Patten
Загружено: 2022-01-15
Просмотров: 4535
Описание:
Designed a custom circuit board using Altium Designer that supports 7 different linear regulators with common input and output. Supporting input and output capacitors are the same and PCB (Printed Circuit Board) layout is similar as well. In this video simple AC noise is measured using an Audio Precision P1+.
Regulators installed:
TLV1117
LP2985
LM317
ADR4525
LT3065 (not working)
78M05
7805
Further tests are planned such ripple rejection and transient response.
