[#5] ESP32 on Zephyr OS: OLED Display (SSD1306) [Part 5]
Автор: The Pull-up Resistor Channel
Загружено: 2023-02-15
Просмотров: 11435
Описание:
In this video, we'll connect an external display, the SSD1306, to the ESP32 using I2C to show a simple 128x64 image.
00:00: Video Introduction
00:15: How the SSD1306 works
08:05: Circuit diagram
09:08: Create the Devicetree overlay
17:50: Configure Kconfig options
18:40: Program the firmware
20:14: Troubleshoot I2C errors
23:47: Implement Zephyr Character Framebuffer driver
27:18: Implement Zephyr Display driver
34:29: Change the contrast to adjust brightness
This is the fifth video in the "ESP32 on Zephyr OS" series, so I recommend watching the previous videos first: • ESP32 on Zephyr OS
