LS Swap 23 - Engine Fuse/Relay Box Modifications
Автор: WorkinOnIt
Загружено: 2023-12-15
Просмотров: 1565
Описание:
3 of 6 on wiring the LS3. We correct improper factory relay wiring, and show techniques for moving pins around in the Fuse/Relay Box.
Specification:
DIN 72552 - Standard for labeling electric terminals in automotive wiring
Parts Used:
Chevrolet Performance 19369375 - Engine Wiring Harness (part of 19421057 E-Rod LS3 Engine Kit)
Song Chuan 301-1C-C-R1 - 35A Resistor Micro Relay (part of 19369375 wiring harness)
GXL-10AWG-GREY - Gray GXL Insulated 10-Gauge Wire
GXL-10AGW-LIGHT-BLUE - Light Blue GXL Insulated 10-Gauge Wire
Aptiv (Delphi) 12129663-L - Tangless Female Terminal for 12-10 AWG
Aptiv (Delphi) 12110842-L - Tangless Female Terminal for 14-12 AWG
Aptiv (Delphi) 12129414-L - Female Maxi-Fuse Terminal
