Ardupilot MinimOSD Setup with Config Tool and FTDI USB Adapter, EZUHF Setup - XUAV Mini Talon Part 5

Описание: Setup and Configuration for the MinimOSD with FTDI adapter and wiring to the APM is covered as well as configuration of the EZUHF LRS receiver with connection by PPM to channel 1 on the APM flight controller. See the link to the EZUHF setup video below for a more in-depth look at configuring the EZUHF receiver.
We focus on using the MinimOSD configuration tool to load the character set and firmware hex file the use the configuration tool to place or move items on the OSD screen.
Remember to update the V2.4 character set first with the old firmware on the MinimOSD because the new V2.4 firmware does not have a character set loader and will fail to update the characters.
After connecting the GPS Compass module I found out that the External Compass Jumper has to be removed for the compass in the GPS puck to work. See Modified Wiring Diagram below.

See Part 6 APM Setup Mission Planner 1 - Update Firmware, APM Compass Calibration, etc.
   • Ardupilot Update APM Firmware, Compass Cal...

Ardupilot web page:
http://ardupilot.org/

APM HKPilot Modified Wiring Diagram:
Go to    • Ardupilot APM 2.6 Wiring, MinumOSD, APM Te...
and Take a picture of the screen around time code 07:40

HKPilot APM with MinimOSD:
https://hobbyking.com/en_us/hkpilot-m...

FTDI to USB Basic Breakout board for MinimOSD
https://www.sparkfun.com/products/9716

MinimOSD Config Tool w/ Character set and Firmware 2.4 r727.
https://code.google.com/p/minimosd-ex...

MinimOSD Firmware 2.4 r795 (Right Click and do Save-As)
http://diydrones.com/forum/attachment...
Found a link to in this post on diydrones:
http://diydrones.com/forum/topics/add...

Setup EZUHF LQ or RSSI on MinimOSD for APM
   • RSSI EZUHF Setup EZUHF LQ or RSSI on Minim...

2.4 Charcter set is on this page, file is called MinimOSD_2.4.mcm
https://code.google.com/archive/p/min...
