FABO MCK-110 Portable Rock Stone Crushing And Screening Plant | 180-300 Tph | Stone Crusher Plant

Описание: Details : https://faboglobal.com/en/products/po...
Contact Number : +90 533 015 28 96

MCK-110 Mobile Hard Stone Crushing and Screening Plant consists of 2 different chassis. In this way, it gains easy transportation feature and offers the opportunity to use both chassis separately in possible situations.
First chassis in systematic order; It is produced with vibrating feeding bunker, double stage grizzly feeder, jaw crusher, front stock band.

Vibrating Feeding Bunker is a system that gains the ability to vibrate with vibro motors and steel springs, and sends the products loaded into the bunker quickly towards the crusher thanks to its vibrating structure.
It has a long service life thanks to its durable body structure and A1 Quality steel springs, which are the biggest factor in vibration.

Jaw crusher is generally used to crush hard and abrasive materials with high silica content such as basalt granite. The jaw crusher, which can easily crush the hardest stone types, has a long service life with its durable structure.
Jaw crusher It is the crusher that crushes the material between the fixed and the movable jaw by compressing and blasting it by means of the elliptical movement of the movable jaw.
Thanks to its hydraulic adjustment system, the jaw opening can be adjusted as desired. In this way, the output product size is determined by the user.
The inner body of the jaw crusher is protected by protective linings. Can be easily maintained and replaced by a staff in a short time.

The belt tires, which are produced resistant to wear, will never let you down and offer many years of service life.
2. Mobile chassis in systematic order; It is produced with secondary impact crusher, vibrating screen, stock and return belts
Secondary Impact Crusher is the secondary crusher used to turn the products crushed in the jaw crusher into sand and gravel.
The secondary impact crusher positioned on the second mobile chassis transfers the products it has undergone from the crushing process to the vibrating screen.
Thanks to the pendulum openings adjusted with the hydraulic system, the final product dimensions can be provided in the dimensions desired by the user.
Hydraulic adjustment of the pendulum system eliminates the need for operator intervention.
The inner body of the breaker is equipped with protection linings. In this way, the wear of the crusher inner body is prevented.
Protection linings are bolted type and offer replacement and maintenance in a short time.

Vibrating Screen separates the products crushed in jaw crusher and cone crusher in the desired size and sends them to the stock area.
The screening dimensions of the Vibrating Screen are determined according to the customer’s request.
Vibrating screen, which gains the ability to vibrate with durable steel springs, can work uninterruptedly under the toughest working conditions.
Thanks to the screen wires that can be changed in a short time, maintenance, repair and replacement processes are completed in a minimum time.

The flap system is a special system that allows the material broken in the crusher to be taken with the help of the front stock band before it is sent to the screen.
The plant disables the vibrating screen when it is desired to obtain a uniform product with the flap system.
The products are transferred to the flap system without being subjected to the screening process.
Flap system minimizes production time with its unique location just in front of the screen

MCK-110 Mobile Crushing and Screening Plant is controlled by a full automation system. Thanks to the automation system panel on the machine, the way the machine works is adjusted.

Equipment that forms the basis of the facility such as crusher, vibrating screen, stock belts, feeding bunker are controlled by the automation system.

Crusher and vibrating screen bearings are temperature sensor controlled. In this way, all bearings are protected against unusual heating.

The automation system that allows you to use the mobile crushing and screening plant in the most efficient way has been prepared with PLC and serves its users with the most advanced state of technology.
