DIY Spindle Sander
Автор: True_Lou
Загружено: 2017-08-01
Просмотров: 113965
Описание:
This is a DIY spindle sander project for either a hand drill or a drill press. The spindle is made of ¾” Plywood disks that were cut out using a hole saw drill (also could use a circle cutting jig). You could make the spindle to any height or diameter needed. The sizes I use for this project are shown in a dimensioned 3D CAD view at the end of the video. Each disk is glued and screwed together, then sanded down as a whole unit to be a perfect circle. A hole is drilled all the way through the spindle to accept a 1 ¼” sheetrock screw (two screws for large spindles). Then a slot is cut in the spindle that bisects the hole for the sheetrock screw. This slot is where the sandpaper ends will be tucked into. A ¼” Hex bolt is clamped down to the spindle with a hex nut & washer. The hand drill or drill press chuck clamps down on the end of the ¼” hex bolt.
There’s a dimensioned 3D CAD view in the video if interested in more details. And if any questions or improvements for this project please comment below. And if you liked the video, feel free like & subscribe to my channel for more.
