Proteus. Importar archivo DXF para contorno del PCB
Автор: AqueronteBlog
Загружено: 2026-02-28
Просмотров: 13
Описание:
#proteus #proteus9 #pcb #pcbdesign #pcbdesigning #dxf
Os muestro como importar un archivo DXF para generar el contorno del PCB en Proteus.
This video shows how to import DXF file to define the PCB edge in Proteus.
03:07 Importar archivo DXF para contorno del PCB
08:18 Posicionar componentes automáticamente en Proteus
Sígueme en GitHub: https://github.com/AqueronteBlog
