Negative voltage power supply with IC 555

Описание: In this video, negative voltage power supply, its a power supply circuit which can produce below ground level voltage, known as negative voltage. This circuit is designed with 555 timer IC. This circuit can be used as negative voltage power supply for low current application.


__________________________________________________________________
Required Components:

IC: NE555 x1

Resistors: 10 K Ohm x 1
2.2 K Ohm x 1

Capacitors: 22 uF x 1 (Electrolyte)
100 uF x 1 (Electrolyte)
10 nF x 2 (Ceramic)

Diode: 1N4007 x 2

Miscellaneous: Multimeters
Breadboard
DC power supply

---------------------------------------------------------------------------------
