Yamaha SMT Pick And Place Machine-YV100-X (Refurbished)
For more details click the link below:
https://www.indiamart.com/proddetail/yamah...
Product Details:
Yamaha SMT Pick And Place Machine-YV100-X (Refurbished)
Specifications:
Model: Yamaha YV100-X (Vintage: 2002-2006)
MC Type: YV100X
PCB size: L460 x W445 mm (Max.), L50 x W50 mm (Min.)or L460 x W335 mm
Accuracy: +-0.1 mm(Chips), +-0.08 mm(QFP)
Mounting Speed: 0.198 sec/chips, 1.7 sec/QFP
Mounting angle: +-180°, per0.01°
Space for cassettes: 100 of 8mmTape, and 80 trays with YTF. (Option)
Available feeders: 8-56 mmTapes, Sticks, Bulks, Trays
Available Components: From 0.6mmX0.3mm to 32 mmX100 mm, Maximum component height 6.5 mm
Maximum mounting data: 10000 mounting line/ 1 production data, Maximum 500 production data in the hard disk.
Machine size: L1, 655XW1, 408XH1, 850 mm
Power Supply: 3-Phase AC 200/208/220/240/380/400/416 V +1-10% 50/60 Hz
Air supply: source 0.55 MPa or more,(4 to 6 Bar) in clean, dry states
Machine weight: 1,450 kg
Contact Details:
Sanjay Shah
Plot No. 1069
Palam Vihar Road
Bijwasan
New Delhi
Delhi
110061
