2.3L F20B STROKER Build Specs and DYNO session!
Автор: BB6 G
Загружено: 2025-07-25
Просмотров: 9227
Описание:
SPEC LIST!! Instagram: @SteezTillDeath
JDM F20b
•BLOCK
-F20b block 86mm bore
-F23A crankshaft - 97mm stroke
-F23A Rods
-K20A2 pistons
-0.040 Headgasket Cometic
-KSTuned balance shaft delete kit
-Approximate compression: 11.3:1
•HEAD
-H22 head, Fully Ported
CAMSHAFTS Skunk2 Tuner 2
-intake valves +1mm
-Exhaust valves std.
-Ferrera valves for both
-BC springs
-BC Steel retainers
-Bronze guides
•INTAKE
-Manifold - Ported
-Double stacked ported plenum spacers
-74mm Skunk2 Throttle Body
-Port matched for Throttle body
-3.5”inch piping, cold air
•EXHAUST
-PLM Try Y header
-Header collector modified to 2.75”inch
-Full 3”inch exhaust after header
•FUEL
550cc Bosch Injectors EV14
-AEM fuel rail + gauge
-OEM Denso fuel pump, brand new
•IGNITION
-SNAKE TUNING COP Kit. "Mini Dizzy"
-NGK Spark Plugs
•MISC.
-Hondata S300 ECU - P28
-Lightweight flywheel 11lb
-FWLR Tuning standalone Knock sensor
-AEM X series Wideband
-Oil Pressure Sensor
Flywheel Competition Clutch 11lbs
-Clutch - EXEDY OEM
-Electric Power steering pump, beltless
