Structural Design #14 Master Column to Footing Rebar Orientation, Hooks, & Constraints
Автор: Rise & Shine
Загружено: 2026-01-17
Просмотров: 39
Описание:
The connection between a column and its footing is one of the most congested areas in structural detailing. If you just place standard rebar, you often end up with column bars clashing directly with the footing mesh.
In this 14th episode of our Structural Design series, we tackle this junction head-on. We look at how to control rebar orientation, adjust hook lengths for varying footing depths, and most importantly, use Constraints to ensure your column starter bars sit perfectly inside the footing reinforcement without clashing.
In this video, you will learn:
Hook Lengths: How to calculate and adjust development lengths and hooks for column starter bars.
Rebar Orientation: Using specific angle settings to rotate rebar shapes for correct placement.
Clash Avoidance: How to set up constraints so that column vertical bars automatically offset to miss the footing mesh.
Smart Detailing: Ensuring your reinforcement model is constructible and clash-free before it ever gets to the site.
Stop manual adjustments and learn to model reinforcement that fits the first time.
Don't forget to LIKE and SUBSCRIBE for more practical Revit Structure tutorials!
#bim #rahidrisenshine #revit
