Tormach 24R - Automatic Tool Changer Installation Video

Описание: The Tormach 24R Automatic Tool Changer allows owners to add an ISO20, 24,000 RPM, ten tool automatic tool changer to their router. This process can be complex, so we made sure to produce this series of automatic tool changer installation videos to help guide you along. This video is not a replacement for the most current document. You must download the most recent version here: https://tormach.com//docs

Owners within the first 96 units of the Tormach 24R may need to install other components before performing the 24R ATC. Links to these Serial Number breaks and their corresponding videos are below.

24R ATC 24R New Power Supply Installation Video - Only for Customers with the SN of RA10,001 to RA10084 (This part will be sent to these customers):    • Видео

24R Z-Axis Brake Video - Only for Customers with the SN of RA10,001 to RA10,096:    • 24R Z Axis Brake Installation Video

Purchase the 24R ATC Upgrade Here! https://hubs.ly/Q01h5_j00

Chapters:
Introduction: 0:00
Serial Number Breaks: 0:20
Begin the Installation: 1:04
Update PathPilot: 1:27
Prepare the Machine: 2:02
Remove the Existing Spindle: 2:33
Install the New Spindle: 3:36
Routing the Wires: 5:11
Rewire the ATC Cable: 5:52
Install the Solenoid Tray: 8:37
Connect the FRL to the Rear of the 24R: 9:56
Connect the Airlines to the Spindle: 11:04
Install the Power Drawbar Button: 11:57
Install the Lift Dust Shoe: 13:05
Install the ATC Communication Board: 14:03
Install the ATC Rack: 15:14
Inspect the ATC Board: 16:53
Adjust the ATC Air Pressure Settings: 17:44
Verify the Power Drawbar Function: 20:44
Verify the Spindle Direction: 21:29
Align the ATC Rack: 22:47
Break in the Spindle: 24:31
Load a Tool into the Spindle: 25:17
Remove a Tool from the Spindle: 25:42
Store the Current Tool into a Pocket: 26:06
Automatically Select a Pocket: 26:28
Select a Specific Pocket: 26:48
Fetch a Tool from a Pocket: 27:11
Remove a Tool from the ATC: 27:30
Measure a Tool: 28:01
Touch off the Entire ATC Rack: 28:18
