Starlinger STAREX extruder line (Wotol ref 2408628-1-AS)
Автор: Wotol Videos
Загружено: 2022-06-03
Просмотров: 1275
Описание:
CHANGEABLE CORE DIAMETER ON WINDER
( 38 mm dia – just for LOHIA circular looms creel !; or ‘regular “ 90 mm dia)
1. Wastes collection into special container in end of the line
2. Fibrilization of tapes available on attachment in line.
FOIL TAPE LINE - STAREX- model 90/1000 - YOC 1996
Composition
1. DOSING UNIT
2. EXTRUDER with 90 mm dia nozzle
3. MELT PUMP WITH DRIVE
4. WIDENING ATT. – 1000 mm max width
5. COOLING BATH
6. WATER /HUMIDITY EXTRUCTION ATT.
7. CUTTING DEVICE
8. OVEN - DRAFTING SYSTEM ( 4 meter long )
9. FIBRALIZATOR
10. GODGETS – 5 pcs
11. WASTE – SUCTION UNIT
12. CONTROL CABINET
13. WINDER OF 250 SPINDLES ( SINGLE WINDING – 1 tape on one spindle) model FIL 23 YOC 1998.
14. WASTE CONTAINER
15. SET OF SPINDLE CORES 35 MM DIA AND 90 MM DIA ( INNER)
Max tape thickness – 0,110 MM MAX
Width of tape minimum – 1.1 mm after drafting
Bobbin inner and outer diameter – 90/100mm, ( or 35/45 mm for Lohia circular looms shuttles)
Bobbin length 280 mm, max dia of full package – 250mm
Including fibrilator.
Max output – 350 kgs/h
Lenght 39535mm
Width 3835mm
Height 4633m
