From truth table to logic circuit - Logism-evolution trick #1
Автор: Skigu
Загружено: 2026-01-28
Просмотров: 6
Описание:
In this video I'll show you how to generate a logic circuit from a truth table. Also you'll learn briefly how a 7-segment display works using bits and how to light up different segments in the display.
If you have any questions, drop a comment and I'll try to answer as soon as possible :)
We'll briefly go through representing numbers in binary digits. How to turn a truth table into a circuit and how to attach a clock and a counter to that circuit to automate it.
To learn the basics of binary, check out this video:
• Binary Explained in under 5 Minutes
List of needed binary digits = bits:
0000 = 0
0001 = 1
0010 = 2
0011 = 3
0100 = 4
0101 = 5
0110 = 6
0111 = 7
1000 = 8
1001 = 9
Each input bit in this project, represents a position in a form like the list above. With just 4 bits we can display the numbers from 0-15, in this project only we use only numbers from 0 to 9.
Leave feedback on this video and let me know if this helped you in any way, thanks!
#digitalcircuitdesign #engineering #logic #circuit #gate #display #wiring #education #logisim #tips #tricks
