PROBLEM 2
Thevenin’s Theorem states that any linear DC circuit seen from two terminals can be replaced by an equivalent single voltage source (Vth) in series with an equivalent resistance (Rth), giving the same terminal behavior for any load.
6 Steps (no description):
1. Identify load and terminals a–ba\text{–}ba–b
2. Remove the load (open a–ba\text{–}ba–b)
3. Find Vth=VabV_{th}=V_{ab}Vth=Vab (open-circuit voltage)
4. Turn off independent sources (V-source → short, I-source → open)
5. Find RthR_{th}Rth seen from a–ba\text{–}ba–b
6. Draw Thevenin equivalent (Vth(V_{th}(Vth in series with Rth)R_{th})Rth) and reconnect the load
Why it is used in DC circuits:
• It simplifies complex DC networks into a single source + resistance, making current, voltage, and power in the load easy to calculate.
• It’s especially useful when the load changes, because you can solve the circuit quickly without re-doing the whole network every time.
