How to create perfect PCB Footprint - What you really need to know
Автор: Robert Feranec
Загружено: 2020-01-13
Просмотров: 79295
Описание:
What pad dimensions should I use and why? Where my pin 1 should be located? What if I do not follow standards? What is IPC about? And more ...
