Op Amps: State Variable Filter Simulation
Автор: Electronics with Professor Fiore
Загружено: 2021-04-13
Просмотров: 4762
Описание:
In this video we examine a four op amp state variable filter via simulation. We compare the high pass, low pass and band pass outputs, and investigate the ability to change the voltage gain and Q of the system.
References: Operational Amplifiers and Linear Integrated Circuits: Theory and Application; Chapter 11, section 7.
My free texts and lab manuals are available for download at my college web site https://www.mvcc.edu/jfiore and at my personal site http://www.dissidents.com
Inexpensive print and kindle copies are available at Amazon https://www.amazon.com/author/jimfiore
If you like my texts and videos, and would like to help defray the costs of making and maintaining them, consider making a modest donation at https://www.buymeacoffee.com/Professo...
