Rebar Modeler Part 1 - Shape Modeling

Описание: How to model complex rebars in AutoDesk Revit based on complex alignments and axes. 3D Reinforcements can be created with SBIM (SOFiSTiK Bridge and Infrastructure Modeler) using adaptive families.
The Rebar Modeler is a development for the SBIM tool for Revit, that not only creates the complex alignemnt of the rebars, but also lets you add and update it.

Chapters:
00:00 Intro
00:14 Modeling Shapes
01:34 Referencing Existing Shapes
02:04 Avoid Rebar Clashes
02:34 Practical Usecases
