TES200 Integrated Circuit Tester IC Chip Tester 74 40 Series Can Judge Logic Gate Good Or Bad

Описание: New Edition Integrated Circuit Tester IC Tester 74 40 Series Can Judge Logic Gate Good Or Bad IC Chips Testing Instrument



1. overview:


TES 200 is a digital integration tester. It mainly tests 74 series and 40 series digital integration. It can test more than 200 kinds of integration.
Easy to use,Testing logic integration can also determine which logic gate is bad. Test integration is selected by key operation.



2. Product application:


Digital integration test, Integrated circuit chip tester, logic gate bad or good judgement



3. Table of Technical Parameters:


Number of items, parameters, units, notes
1. Working voltage 7-12 VDC
2. Working current less than 30 mA
3. Operating temperature - 40 to 65 degrees Celsius.
4. Storage temperature - 40 to 65 degrees Celsius
5. Size: 70*45*40 mm long, X wide and X high



4. Interface Description and Related Operations


JK1 Power Interface (DC Head D13): Positive and negative. Voltage (7-12V) DC regulated power supply.
SW1 power switch
ON: Power on.
OFF: Power off status.



5. Keypad


MODE: Select the integration type. (74 or 40 series)
UP: Select the last integrated model.
DOWN: Select the next integrated model.
TEST: Test the selected integration model.



Note: When installing test integration, it is aligned downward.


74 Series
7400 ,7401 ,7402 ,7403 ,7404 ,7405 ,7406 ,7407 ,7408 ,7409
7410 ,7411 ,7412 ,7413 ,7414 ,7415 ,7416 ,7417 ,7418 ,7419
7420 ,7421 ,7422 ,7424 ,7425 ,7426 ,7427 ,7428 ,7430 ,7432
7433 ,7434 ,7435 ,7436 ,7437 ,7438 ,7439 ,7440 ,7442 ,7443
7444 ,7445 ,7446 ,7447 ,7448 ,7454 ,7464 ,7470 ,7472 ,7473
7474 ,7475 ,7476 ,7477 ,7478 ,7480 ,7482 ,7483 ,7485 ,7486
7487 ,7489 ,7494 ,7495 ,7496 ,74101 ,74102 ,74103 ,74107 ,74108
74109 ,74112 ,74113 ,74125 ,74126 ,74128 ,74130 ,74132 ,74133 ,74134
74135 ,74136 ,74137 ,74138 ,74139 ,74140 ,74145 ,74147 ,74148 ,74151
74152 ,74153 ,74155 ,74156 ,74157 ,74158 ,74160 ,74161 ,74163 ,74164
74165 ,74166 ,74171 ,74173 ,74174 ,74175 ,74176 ,74177 ,74180 ,74182
74190 ,74191 ,74192 ,74193 ,74194 ,74195 ,74197 ,74242 ,74243 ,74247
74248 ,74249 ,74251 ,74253 ,74256 ,74257 ,74258 ,74259 ,74260 ,74266
74279 ,74280 ,74283 ,74290 ,74293 ,74295 ,74298 ,74350 ,74352 ,74353
74365 ,74366 ,74367 ,74368 ,74375 ,74378 ,74379 ,74390 ,74393 ,74395
74425 ,74426 ,74445 ,74447 ,74490 ,74595 ,74670


40, 45 Series
CD4000, CD4001, CD4002, CD4006, CD4007, CD4008, CD4009, CD4010, CD4011, CD4012,
CD4013, CD4014, CD4015, CD4016, CD4017, CD4018, CD4019, CD4020, CD4021, CD4022,
CD4023, CD4024, CD4025, CD4026, CD4027, CD4028, CD4029, CD4030, CD4033, CD4035,
CD4040, CD4042, CD4043, CD4044, CD4048, CD4049, CD4050, CD4051, CD4052, CD4053,
CD4060, CD4066, CD4068, CD4069, CD4070, CD4071, CD4072, CD4073, CD4075, CD4076,
CD4077, CD4078, CD4081, CD4082, CD4085, CD4093, CD4094, CD4099, CD4502, CD4503,
CD4504, CD4510, CD4511, CD4512, CD4516, CD4518, CD4520, CD4522, CD4526, CD4529,
CD4532, CD4539, CD4543, CD4555, CD4556, CD4584, CD40106, CD40110, CD40161, CD40162,CD40174, CD40175, CD40192, CD40193
