3_SIEMENS S7 300 EMULATOR | COMMUNICATION | WINCC SCADA | KEPSERVER

Описание: SIEMENS S7 300 PROGRAMMING |WINCC SCADA | USING KEPSERVER
In this video, I will tell you about SIEMENS S7 300 PLC programming software, Intouch SCADA and we will make and develop the logic.
COMMUNICATION BETWEEN PLC AND SCADA

✅ SIEMENS S7 300: CPU317-2 PN/DP
INPUT:
1) Start: M0.0 or I0.0
2) Stop: M0.1 or I0.1

OUTPUT: Q0.0

✅ NET TO PLC SIM:
Network IP Address: 169.254.62.200 (virtual adapter)
PLC SIM IP Address: 192.168.0.1 (bydefault selection)
RACK: 0 SLOT: 2

✅ WINCC SCADA

🟢 TAG MANAGEMENT

ADD OPC UA WINCC CHANNEL
1) New connection name: S7_300

2) Connection Parameter :

🟡 Search in search box for "opc ua configuration"
🟡 Double click on 1st URL copy address

🟡 Go in Tag Management and then OPC UA WINCC CHANNEL then S7_300
🟡 Right click: Add Connection Parameter
🟡 Double click to add server
🟡 paste URL copied from OPC UA Configuration then ok
🟡 Security Policy : Basic256Sha256
🟡 Security mode: SignandEncrypt

🟡 Authentication Settings: Anonymous then ok
🟡 Right click on "S7_300" and Open OPC Browser Server
🟡 Click on SIEMENS and expand
🟡 Click on "S7_300"
🟡 Tick all tags
🟢 All tags available in Tag Management

Thank you for watching!!
