Cardan shaft balancing machine BVI-03-88 VTM Group

Описание: DRIVESHAFT BALANCING MACHINE BVI-03-88


Balancing machine for professional repair of cardan shafts up to 200 kg.
The hard-bearing machine is adapted for heavy cardan shafts of trucks and special machinery. The high sensitivity of the supports allows also high-quality balancing of cardan shafts of passenger cars.

The machine is designed for balancing cardan shafts in the facilities of cardan repair workshops. The machine can be quickly reconfigured for balancing a large amount of single cardan shafts of various designs, as well as for the production of small batches of shafts.


TWO TIMES faster then your machine.

This balancing machine is majored to balance the shaft not only qualitatively, but also quickly.
If you can balance in 2-2.5 times faster, then this is your real competitive advantage.



HIGH PERFORMANCE ACCESSORIES
The machine is equipped with three main types of adapters:

1. Fast clamping universal adapters. It has two main advantages: The first is that due to the special design the driveshaft flange is clamped within 5 seconds. This advantage is due to the fact that the driveshaft flange does not need to be fixed with bolts.
THE SHAFT CAN BE CLAMPED
2 TIMES FASTER WITHOUT BOLTS.

The second advantage is the centering rings. The driveshaft is mounted in the adapters with centering rings that can be made on an ordinary lathe to fit most common driveshafts.

2. KV Flange adapters. Applies to four flange sizes: 120, 150, 180, 205 mm. Used for balancing shafts with cross-tooth flanges on truck driveshafts.

3. Adapter with slots. Used to mount various flanges with holes. Mounting the driveshaft is the same as on universal adapters, with the help of centering rings.



KEY FEATURES
• Balancing of 2, 3 and 4-support cardan shafts
• Shaft length up to 5200mm, weight up to 200kg
• Cardan installation in 1 minute
• Standard set of adapters - Installation of 80% of cardan shafts;
• Three ways of fixing the center bearing
• Hard-bearing type machine - safe balancing of shafts with large initial unbalance
• Machine is operated by one worker
• Sliding tailstock spindle - quick changeover, comfortable operation
• Safety bracket with clamp for quick installation
• Measurement in all planes at one time
• Calibration of the machine by the operator
• Displays imbalance in real time
• Create and print reports
