The Macintosh IIsi: Can I Finish the Power Supply & Repair a Logic Board? (Computerized Start™ Live)

Описание: The Macintosh IIsi was launched as a lower-cost alternative in the Macintosh II series. To keep costs down, Apple used more electrolytic capacitors, and the surface-mount electrolytic capacitors from the early 90s are past their expected lifetime. In addition, despite the power supply being made by Sony, the capacitors in it are also known to leak (though I can't help think "cost tweaking" by Apple led Sony to use lower grade capacitors).

Due to the extent of the damage to the original power supply, I ordered PCBs to construct a replacement power supply that fits in the original power supply case. I need to finish assembling that power supply, including making a few mods to it to improve performance (in a "make sure there is a ground connection kinda way).

Once I've done that, I need to start the process of locating faults.

Will I trip the circuit breaker? Will I find the cause of the vertical lines? Did I order the correct 74ALS245 package type? You'll have to watch to find out!

*

Table of Contents
0:00:00 Pre-Roll
0:02:39 Greetings and Announcements
0:05:20 Things You All Have Given Me: 3D Printed Bracket and Memories from ‪@RetroTechChris‬
0:10:33 Retro Bits and Bytes Swap Meet Pick-Ups
0:16:49 Wheel of Regrets™ (Who comes up with these titles anyway?)
0:17:11 Wheel of Regrets™: My Order from ‪@i80386sx‬'s eBay Store (Not Actually a Regret™)
0:24:55 Wheel of Regrets™: Nintendo Game Boy DMG-01 Parts
0:45:13 Getting the Macintosh IIsi (number 2) and Other Parts
0:48:02 Yes, Apple Made a "Trident" Card (mine's bad)
0:50:17 Finishing the Power-Up-llusi, with Mods
2:16:03 Setting Up for a Power Supply Smoke Test
2:20:23 Power Supply Smoke Test Time
2:23:28 We Have a Video Signal - With Vertical Lines - from the IIsi (number 2)!
2:25:10 Let's Tackle Those Vertical Lines
4:14:02 Closing Thoughts
4:22:55 Outro

*
