Measuring a MOSFET’s Miller Plateau - Workbench Wednesdays
Автор: element14 presents
Загружено: 2020-07-08
Просмотров: 32338
Описание:
Turning on a MOSFET takes more than knowing the threshold voltage. A special event occurs when a FET turns-on, which is called the Miller Plateau. The gate voltage sticks to the threshold voltage while the drain opens up. In this video, James shows how to measure the Miller Capacitance, using an oscilloscope and custom MOSFET test board: https://bit.ly/3iEMH5v
Engage with the element14 presents team on the element14 Community - suggest builds, find project files and behind the scenes video: http://bit.ly/2MFMG0v
Visit the element14 Community for more great activities and free hardware:
Tech spotlights: http://bit.ly/2KLz0TS
Roadtest and Reviews: http://bit.ly/2KH4fj3
Project14: http://bit.ly/2wPnajx
