Cruiser LED 1000 BWSF, LH-C804

Описание: Technical Specification


Power

Input Voltage:100-240V 50/60Hz

Power Consumption: 950W

Gobo

Static gobo wheel :9gobos+ open

Rotating gobo wheel : 7gobos+ open

Outside diameter:18mm

Image diatmeter:25.6mm



Head movement

Pan /Tilt:540°/270°16bit with auto position correction

Light Source

Light Source:700W LED module

Color Temperature Output of Fixture: 6200K

Life expectancy:About 50000Hours

( factory rated)

Effect

Effect wheel: 1 aluminium animation wheel

Other Function

Dimming：0-100% linear dimming system

Strobe: 1-20F.P.S, speed adjustable

Focus:Electronic focus function

Cooling system: Low noise and effcient fan cooling system

Zoom Range

Zoom range: 5°- 45°

Framing System

Framing shutters: 4 individual shutter blades plus rotation

Iris: Motorized, pulse effects up to 3 Hz

Housing

Housing: Magnesium alloy body

Working Environment: -10℃-45℃

Protection Rate: IP65

Control

Display: LCD display

Control mode: DMX512, master-slave,auto,RDM

Channel: 51/43/50/42/49CH



Prism

Prism: 6-facet circular prism



Connection

Power connection: Powercon in/out

DMX connection: DMX 3-pin + 5-pin in/out

Colors
Color wheel 1 :5 colors+ open

Color wheel 2: 5 colors + open

CMY:Linear CMY color mixing

Variable CTO: 2700-6200K linearly adjustable

Frost

Frost: 2 frost filter, light and medium

Physical Information

ProductDimension:

396*310*751mm

Net weight:35kg
