Viavi smart otdr expert alarm settings | Config viavi traces setup files

Описание: Dear viewers in this video session we going to talk about Viavi smart otdr expert alarm settings and before part-1 was about acquisition setting discussed moreover, this video is the continuous about Config viavi traces setup files. This made video for those who want to know like How to expert setting of viavi smart otdr or How to use t-berd 2000 smart otdr and may be How do I setup my viavi otdr. We bring the viavi solutions for the better utilization of your fiber link net work. So, for efficient network Viavi alarm settings part-2 2022 make you better understand your network management. The alarm setting is the part of Viavi smart otdr expert mode settings. This video base on Viavi smart otdr user manual reference. For the personnel who want to Viavi training videos from the basic like "What is smart otdr" and Viavi otdr training hindi rather particular model of Viavi smart otdr in hindi as well as smart otdr training in urdu for both South Asian region ease to understand in thier mother tongues.
  UHKtechnopedia made this video viavi smart otdr setup overview of Optical time domain reflectometer as reference for other brand to make it better in thier knowledge. I wanna share the Viavi smart otdr basic expert settings. Herd is the reference of Viavi smartOTDR manual.

Configuring the Alarms parameters:
In the Setup page, press Alarms softkey (if one parameter is selected in the current screen, press Top Menu soft key to display the right menu keys and click on Alarms).
Once the Alarms page is displayed, configure the parameters for applying thresholds to results displayed.

Threshold:
• None
      The alarm function is not active

• User
Thresholds can be defined for: Splice Loss / Connector Loss / Reflectance / Splitter Alarm / Slope / Fiber Length Min and Max / Link Loss Min and Max / ORL.

   TIA-568 C / ISO/IEC 11801 / Default / G.697/G.98x PON / G.697/IEEE PON
Select one of this parameter to configure the alarm thresholds with predefined values.

If results are not you putt the selected value those thresholds, they are highlighted in red in the table of results, and the icon appears at the top right of the screen.
If all the results lie within the thresholds (no result is in red or yellow), they are displayed in green in the table and the icon is displayed at the right top of the trace.
