How to Install a Mini Thermocouple Connector Wire Clamp Bracket
Автор: Harold G. Schaevitz Industries
Загружено: 2019-12-27
Просмотров: 10212
Описание:
We have a newer version of this video available!
Watch here - • How to Install a Mini Thermocouple Connect...
Instructional video demonstrating how to install our wire clamp bracket to a Mini Thermocouple Connector. For more information visit us at www.thesensorconnection.com - Harold G. Schaevitz Industries, The Sensor Connection USA.
How to install a Mini Thermocouple Connector Wire Clamp Bracket.
Materials:
Screwdriver
Thermocouple
Wire Clamp Bracket Kits:
Mini Thermocouple Connector
Grommet
Bracket
Clamp
Pair of 0.37” long screws
Pair of 0.29” long screws
Remove cover from connector.
Remove both screws from cover and discard.
Slide grommet over wire.
Loosen screw terminals that hold wires in place.
Secure wires under screw terminals.
Replace cover.
Place bracket on top of cover.
Secure bracket with 0.37” long screws.
Flip connector over.
Secure clamp & wires with 0.29” long screws.
Installation successful!
Thanks for watching!
