Putting an Automotive Relay into my ZD-915 Desoldering Station

Описание: I'm hacking an automotive relay into my desoldering station to circumvent the long wiring activating the vacuum pump. // Kindly sponsored by my favorite PCB manufacturer PCBWay! https://www.pcbway.com/

My previous ZD-915 modding video:
   • ZD-915 Desoldering Station Repair & Mods

The tutorial I got this idea from (German forum):
https://circuit-board.de/forum/index....

I used a Hella brand 12V closing automotive relay and a 1N4007 diode for this mod.

TIME STAMPS:
0:00 Introduction
3:40 Schematics for the Mod
6:01 Sponsor Message
6:32 Finding the Connection Points
11:06 Making Contact
16:49 Flyback Diode
18:05 Connecting the Relay
19:57 Smoke Test
20:52 Setting the Pump Voltage
22:22 Final Assembly
23:48 Real Life Testing
25:11 Thank you & Good night

---------------------------------------­-----
