VCDS "VAGCOM" B8 & B.5 AUDI S4 CLUTCH ADAPTION . Dual Clutch

Описание: Car in Video : AUDI 2014 S4

Quick video for Clutch Adaption for 7-Speed S-Tronic Direct-Shift Gearbox (DSG/0B5)

Basic Setting
Prerequisites:
Transmission fluid level correct
Transmission fluid temperature between 40°C - 100°C. (one user reports this needs to be below 60°C)
TCM fault free however it is strongly recommended to check/clear all Powertrain controllers faults also.
Key on, Engine off
Selector lever in P

All 3 Basic Setting operations need to be completed in the order listed below

[Select]
[02 - Auto Trans]
[Basic Settings - 04]

Select Erase counter for start and stop processes
[Go!] to activate the Basic Setting.
After the result of Finished Correctly or Not Running appears click [Stop]
[Done, Go Back]

Start the Engine and leave the Selector lever in Park

[Basic Settings - 04]
Select Clutch valve calibration [Go!] to activate the Basic Setting.
After the result of Finished Correctly appears click [Stop]

Select Distance sensor calibration
[Go!] to activate the Basic Setting.
Clunking noises from the transmission are normal
After the result of Finished Correctly appears click [Stop]
[Done, Go Back]

Switch off Ignition, wait 10 Seconds and switch it back on.
[Fault Codes - 02]
Check and clear any fault codes
[Close Controller, Go Back - 06]
Perform a test drive and check for fault codes again after doing so.


http://wiki.ross-tech.com/wiki/index....)


hope it helped
