Stanko (Russia) 5M161 Heavy-Duty Gear Shaper Machine - 1250 mm Gear Diameter x 12 Modules Capacity

Описание: Heavy-Duty Gear Shaping Machine made by Stanko (Russia) in excellent working condition. The model of the machine is 5M161 and the Maximum Module Capacity is 12 Modules. The Maximum Diameter of the Gear is 1250 mm and the Maximum Stroke Length is 200 mm. The machine is complete with its Change Gears, Operating Manuals, Electrical Drawings, Hydraulic & Mechanical Drawings, and other accessories etc. The overall condition of this machine is as good as new and all the features are working perfectly fine. The technical details are as follows -

Make - Stanko (Russia)
Model - 5M161
Max. Module Capacity - 12 Modules
Max. Length of Stroke - 200 mm
Max. Diameter of Gear - 1250 mm
Table Diameter - 1000 mm
Stroke Rate - 33 strokes/min to 212 strokes/min
Height between Table Top to Machine Body - 345 mm
Table Bore Diameter - 120 mm
Weight of the Machine - 10.7 tons (approximately)
Motorised Rapid Travels in Spindle Rotation & Spindle Travel.
Motorised Rapid Travels in Table Rotation & Table Travel.
Complete with Change Gears, Operating Manual, Electrical Drawings etc.
Machine is in excellent working condition.
