Raimondi Gladiator 105 Advanced Wet Tile Saw
Автор: Contractors Direct
Загружено: 2008-11-18
Просмотров: 35559
Описание:
http://www.contractorsdirect.com/Hold... - Buy Hold Down Guide For Raimondi Gladiator 105 or Raimondi Zipper 105 saws
Call Contractors Direct at 1-800-709-0002 for More Information
Visit us at: http://contractorsdirect.com/
Like Contractors Direct on Facebook:
http://contractorsdirect.com/facebook
Follow us on Google Plus
http://contractorsdirect.com/google
Follow us on Twitter
http://contractorsdirect.com/twitter
• Re-adjustable square for long lasting precision.
• Telescopic legs provided with safety device to prevent collapsing.
• Floating blade guard remains in contact with tile to provide extra safety during operation.
• Pivoting blade guard remains parallel with tile to ensure maximum cutting depth.
• Equipped with: diamond disc Ø 250 mm (10) for porcelain.
• Wheels kit for easy transpor. Key kit, wrench, manual.
• For cutting granite, marble, porcelain, single and double fired, bricks, cement, etc Straight, 45° bevel (Jolly) & plunge cuts.
• Maximum length of cut 41 3/83/8
• Maximum thickness of cut: 3 1/8 (80mm); 6 (150mm) in double pass.
• Maximum blade diameter 10; smallest blade diameter 9.
• Adjustable cutting depth.
• Tilting motor assembly for bevel cuts from 0° to 45°.
• Belt driven system optimizes motor torque and cutting capacity. Gear ratio of motor to disc 1,4 ÷ 1. Drive belt type poly V.
• Cast and extruded aluminum framework.
• Easy-to-remove polypropylene tank for easy cleaning. Capacity: 10 Gal..
• Heavy duty water pump and (2) jet nozzles (front or rear mounted) provide superior blade cooling.
• Sliding motor assembly with cast aluminum housing provided with 4 re-adjustable pulleys (double bearings, only 2 are adjustable). Extruded aluminum rail.
• Re-adjustable square for long lasting precision.
• Telescopic legs provided with safety device to prevent collapsing.
