Maple Leaf - The “Quick Released”Bolt System Operate Guide For MLC-338/MLC-LTR

Описание: We remove the stock/chassis to show you that how this system works.

FIRST, MAKE SURE THE RIFLE IS EMPTY OF BB AND THE PISTON IS RELEASED. (NOT COCKED)

Remove the Bolt :
1.Press the cocking indicator button to release and drop down the Set Pin. (Spring Guide Sear)
2.The Set Pin will drop down inside the rifle smoothly, if not, make sure the cylinder is not tilted or will stuck the Set Pin.
3.Pull back the cylinder out from receiver.

Insert the Bolt :
1.First, make sure the Safty is OFF, then press the Bolt Handle Safty Lever forward and pull the trigger at same time.
2.Press the other end of cocking indicator button and put the cylinder into the receiver, then lock the bolt handle.
3.Upside down the rifle ,then press the cocking indicator button Again to reset the Set Pin (Spring Guide Sear) Again, if the Set Pin does not drop back smoothly, make sure the clylinder is not tilted.

我們事先移除了槍托，只留下上段來向各位展示整個快拆系統如何運作

新式快拆槍機系統-操作說明：
"操作前請先確認槍膛已淨空沒有BB彈，活塞已向前釋放(無後定)"

移除槍機汽缸：
1.按下槍機釋放紐，來釋放尾頂桿固定插梢，插梢會自然落下。
2.尾頂桿固定插梢會順暢地落下於槍身中，如果沒有，請確認汽缸沒有左右偏擺導致卡住插梢，影響正常掉落。
3.慢慢向後抽出汽缸即可

裝回槍機汽缸：
1.首先確認保險已關閉，接著將 "槍機拉柄保險" 往前推並同時扣下扳機。
2.按下槍機釋放紐另一側，並放入槍機汽缸推到底後，關上槍機拉柄。
3.將步槍上下顛倒，再次按下槍機釋放鈕，讓尾頂桿固定插梢落回原本位置便完成。
再次提醒，如果插梢沒有順利落回，請確認汽缸是否有左右偏擺而卡住插梢。
