STM32 USB 2.0 High-Speed Tutorial (ULPI + MSC + SDRAM) - Phil's Lab
Автор: Phil’s Lab
Загружено: 2025-12-22
Просмотров: 16276
Описание:
Firmware and hardware tutorial on how to interface STM32 MCUs with USB 2.0 High-Speed (HS) PHYs. Testing via USB mass storage device (MSD) class with external SDRAM on a custom STM32-based hardware platform.
Limited-time: $2 for 6-layer PCBs up to 100×100 mm - grab your $33 coupon now: https://jlcpcb.com/events/6-layer-pcb... (Ad)
Altium Develop: http://altium.com/yt/philslab
[SUPPORT]
Hardware design courses: https://phils-lab-shop.fedevel.education
Course content: https://www.phils-lab.net/courses
Patreon: / phils94
[LINKS]
USB FS + SD MSC Video: • (Sponsored) STM32 USB SD Card Mass Storage...
SDRAM Video: • (Sponsored) SDRAM Hardware & Firmware Tuto...
ULPI Blog Post: https://resources.altium.com/p/usb-hi...
USB HS DMA Fix: https://community.st.com/t5/stm32-mcu...
[TIMESTAMPS]
00:00 Intro
02:07 JLCPCB (Ad)
03:09 Altium Develop (Ad)
04:16 Hardware Walkthrough
11:27 CubeIDE Peripheral Set-Up
21:21 Firmware
27:53 Demo & Test
31:25 USB DMA
33:00 Increasing MSC_MEDIA_PACKET Size
34:59 Outro
