Front Loading Component Cleaning & Degreasing Machine
DESCRIPTION :
The Ultramax Front Loaded Rotary Cabinet Washer designed for Heavy Duty component washing for large parts, machined bodies and batch type production with greater load capacities for handling larger parts than our top loading Roto Cabinet Washer models. Front loaded rotary cabinet washer efficiently cleans the `components’ kept on a trolley at the load / unload platform of the machine. When the `Cycle Start’ button is pressed, the trolley slides inside the cabinet. The front door closes automatically. Our Cabinet Component Cleaning Machine operates with a gear-driven turntable and provides easy access to component washing, efficient & safer in operation the component inside the chamber on the rotary table rotates; the pressurised hot alkaline solution is sprayed over the components.
In day to day operations in Front Loading Spray Washers the main challenge is to maximize efficiency and achieve greater return on investment. Our Front Loading Rotary Table Type Spray Washer provides excellent part cleaning capabilities that exceed the most rigorous customer demands. Our Front Loaded Rotary Cabinet Washer excellent for railroad, re-manufacturing, mining, marine, energy and other heavy-duty industry cleaning applications. We ensure higher levels of component surface cleanliness are achieved during the design & process selection prior to manufacturing.
PROCESS :
• Aqua based alkaline high pressure spray over the component in Rotary Spray Wash Cabinet
• Recirculation Rinse & fresh water rinse system
• Cold & Hot Air Blow.
• Fine Filtration system
• Both side loading & Unloading option available.
• Auto Detergent Dosing Unit
• Auto water fill – ensure the system always has enough water



ACCESSORIES :
• Wash & Rinse tank
• Stainless steel construction for all wetted components.
• On line & off line Filtration system – 5 to 150 micron bag filtration
• PLC Controlled Electrical panel
• Stainless steel disc oil skimmer.
• Oil separating systems
• Sludge extraction systems
• Steam exhaust Mist collector systems
• Pump capacity variation in pressure & flow rate according to the component & suitable design of Front Loaded Rotary Cabinet Washer.
• High capacity Inconel heaters
• Tank & Booth Insulation
SPECIFICATION :
• Roto Cabinet Washers Wash pressure varies from 4 to 40 bar.
• Front Loading Spray Washer Rotary table are driven by sprocket arrangement for reliable excellent performance.
• Vertical Pump Systems – the ultimate in pump reliability
• Mechanical well designed leak proof Door no need for any seal replacing!
• Power spray swing nozzle for high effective cleaning.
• Automatic pneumatic lift doors
• Front Loading Rotary Table Type Spray Washers table diameter available from 800mm to 2500mm.
• User friendly for handling heavier components by hoist or cranes.
• Perfectly fits into the cellular manufacturing layout
• Single operator has to handle multiple machines at a time
• PLC Controlled Electric panel.
• Load carrying capacity of our Spray Cabinet Parts Washer 150 kg to 3500 kg
• Wash solution tank capacity vary from 300 to 3000 Litre depends upon the Spray Cabinet Parts Washer design requirement of the component.
• Low Water Shut-Off – Protect your heat elements from low water conditions & running the system dry
• Industrial Control Panel with international wiring standards for numbering, sizing, color coding, and overload protection.
• Digital Display Temperature Controller
• Various Voltages Available on request.

APPLICATION :
• Transmission component washing
• Diesel Engine Degreaser
• Large Parts industrial degreaser
• Military Applications Degreaser
• Aircraft Wheel Parts Washer
• Aircraft Brake Parts cleaner machine
• Aircraft Bearing Parts Washer
• Diesel Engine component washing machine
• Electric Motor Parts Washer
• Rail Bearing Parts Washer
• Locomotive Crankcase Washer
• Machined casting cleaning machine.
• Steel Mill Bearing Parts cleaner machine
• Wind Turbine Gearbox Parts Washer
• Diesel Engine cleaning machine.
• Diesel Cylinder Heads with Carbon Cleaning
• Rail Bearing Washing and Degreasing
• Locomotive Engine Rebuilding.
• Aluminium Engine Head with Carbon deposits cleaning
• Electric Motors washing
• Diesel Transmission component cleaning
• Aircraft Wheel cleaning to remove the Rubber Bead
• Machine Suitable for Cleaning of Gears, cleaning of Cam Shaft, cleaning of Transmission housing etc.
