G238D JIS Rubbing Colour Fastness Tester-QINSUN
Автор: QINSUN Qinsun Instruments Co., LTD
Загружено: 2020-06-08
Просмотров: 621
Описание:
This rubbing color fastness tester is a standard testing machine of the Type II rubbing tester (GAKUSIN TYPE) specified in JIS L0849 Test Method of Rubbing Fastness in JIS Textile-Tests For Color Fastness. It is applied to determine the color resistance of dyed or printed textiles to rubbing thus providing evidence for textile products R&D and acceptance inspection. It is reported that this tester is stricter than the ordinary horizontal reciprocation rubbing color fastness tester whose evaluating results are worse with the same specimen tests. Textiles exported to Japan should present test results by this device. 50mm rub heads and auxiliary weights are equipped for cardboard rubbing resistance tests.
Standards:
JIS L0849, JIS L1084, JIS L0862, JIS P8136, JIS L1084
Specifications
Model :238D
Stations :6
Rub heads:Curved surface R45mm, width 20mm
Rub heads load:2N
Rub area length:100mm
Reciprocal speed:30rpm
Load weight:300g,500g,800g
Rub cloth fixing method:Spring clip
Counter: 220V, 50Hz
E-mail: [email protected]
