PSAD Refresher 46: Analysis of Symmetrical Parabolic Cable
Автор: Engr. Harf Miranda (Sir Harf Engineering Tutorial)
Загружено: 2025-02-01
Просмотров: 1195
Описание:
SITUATION: The cable shown supports a horizontally distributed load of w.
1. If w = 9 kN/m, calculate the minimum tension (kN) in the cable.
A. 165.20 C. 260.65
B. 125.65 D. 168.75
2. If w = 9 kN/m, calculate the maximum tension (kN) in the cable.
A. 245.62 C. 375.65
B. 181.75 D. 288.91
3. Calculate the maximum w (kN/m), if the breaking strength of the cable is 120 kN.
A. 3.18 C. 5.94
B. 5.47 D. 2.98
Thanks for watching!
Comment for questions and suggestions for future lecture in this series.
Subscribe and hit the bell button to be notified for future posts.
