Solar Edge Inverter Master & Slave Connection
Автор: SolarCellz
Загружено: 2018-02-24
Просмотров: 22664
Описание:
Visit us: http://www.solar-cellz.com
Solar Edge Tutorial Multiple devices, RS485 bus, wired Ethernet connectionDescriptionIn this configuration multiple devices connect through the same RS485 bus in a master/slave configuration. Only the master is physically connected to the internet through the Ethernet port.Required EquipmentCAT5 or CAT6 Ethernet cable with RJ45 connectors. Max distance: 100 meters / 300 ft. (from master device to router)Ethernet routerRS485: 4-conductor cable. Max Distance: 1000 m / 3000 ft. (from the first to last device. The master does not have to be the first or the last one)SolarEdge Device RS485 and LAN ConfigurationIn the LCD menu, select the following:For the slave devices: The SolarEdge devices are preconfigured to use the RS485-1 port by default. If using RS485-2 (in devices where supported), select the following in the LCD menu:Communication è RS485-2 Conf è Device Type è SolarEdgeCommunication è RS485-2 Confè Protocol è SlaveCommunication è Server è RS485
