RtReports - Reporting on Multiple Child Event Frames using Iterators

Описание: Use Iterators to report on multiple (or variable number of) Child Event Frames (Unit Batches and Subbatch Levels).

[00:45] Go over existing report not using Iterator to report on one Child Event Frame.
[02:10] Discuss that journal has 3 entries for our 3 units (Chile Event Frames). We would like to be able to report on multiple Child Event Frames without having to create three entries manually in the Format Template. This is completed with Iterators.
[02:33] Create new Section in the Format Template to demonstrate the use of Iterators.
[03:30] Add Iterator to the Entry so it is repeated for each UnitBatchJournal.
[04:29] Add Event Frame Name as a Data Item within the Iterator. Notice that the Source does not include the section already included in the Iterator above it.
[05:44] Add the PIUnitName, Procedure, and Child Event Frame Start and End Times.
[09:25] User filter criteria in an Iterator. This section will only be used for Mixing Steps based on a “Name” filter.
[11:11] Copy Mixing Unit Entry. Edit this copy to be used only for Heater Units by changing the “Name” filter.
[12:10] Use of nested Iterators to report on the two Heater Elements within the Heater Step. Edit the Format Template to add basic information about the Heater Elements to the report.

This video is part of a series showing examples of RtReports v4.1 which includes support for Event Frames.
