Suzuki SX4 front wiper washer hose replacement
Автор: zmanvideo1
Загружено: 2018-03-11
Просмотров: 11075
Описание:
Suzuki SX4 front wiper washer hose replacement by hood hinge.
@ 6:55: The reason I had to disengage part of the cowel is so I could pry up gently to cut the electrical tape that was holding the hose to the bracket, sorry but I forgot to show a clear picture of this. NOTE: the hose is attached via electrical tape at 2 locations: 1st at 2:23, 2nd at 6:55 (pic not shown). If you gently pry up on the cowel you can cut the tape and remove the old hose. The wire tie I show @ 5:17 is at the 1st location.
Subsequent removal of this hose will not require prying up on the cowel or removal of any brackets. The wire tie can be cut through the body panel with a pair of long reach mini needle nose pliers.
Size of the clear plastic hose is 1/4 inch exterior diameter and 1/8 inch interior diameter. The hose will only fit on the fittings if you use a heat gun or dip the end of the hose into hot water to expand and soften it. If you use a thicker diameter exterior hose it will not fit in-between the cowel and body frame.
@ 6:19/10:50/10:58 I should have said 1/4 inch loom wire protector.
Hope this helps.
Thank your for watching.
