Making Sense of Overdrive Wiring on our Triumph TR4 | British Car Wiring Tips and Tricks

Описание: We focus on overdrive wiring and other loose ends on our 1964 Triumph TR4 in an effort to wrap up our interior restoration. Will we keep the harness smoke inside the wires? Or will the "Prince of Darkness" strike again? Find out this week on WEGS GARAGE!

The Laycock de Normanville A-Type overdrive does not appear to have been original to our car. As a result, the wiring harness has none of the provisions needed to wire the relay, limit switches, and solenoid.

Triumph did not fuse the overdrive solenoid on the TR4. However, later cars such as the Triumph TR6 did have a fuse. We added a 10 amp ATO automotive fuse into our circuit. This is an easy upgrade to help reduce the risk of failures and burnt wires in the overdrive circuit!

0:00 Intro
1:32 Overdrive Switch
3:19 Wiring Diagram Schematic
5:00 Overdrive Fuse Sizing
6:28 Heater Fan Switch (again...)
7:20 Turning on the Power
8:25 Wire Harness Details
10:14 Custom Relay Panel
12:00 Outro
