30X Drone Zoom Camera With Object Tracking

Описание: Camera product link: http://www.yangdaonline.com/sky-eye-3...
Drone product link: http://www.yangdaonline.com/yd6-1000s...

Sky Eye-30HZ-S is a 3-axis high stabilized gimbal with 1080P 30X zoom camera for drone inspection,surveillance,search and rescue applications.The camera block is SONY FCB-EV7520, which provides 1080P 60FPS full HD video streaming and up to 360X zoom capability,which will enable you to see every detail you need in the air even you are far away from the object. High-performance 3-axis gimbal is using advanced FOC(field-oriented control) motor control technology which will enable you to get a 0.01 degree incredible precise control, so the gimbal will give you crystal clear and stable video footage.

Compact and lightweight
Sky Eye-30HZ-S weighs as little as 848g to help you meet your payload weight allowance.

Easy for integration
Sky Eye-30HZ-S comes with an amazing advantage that the gimbal can not only be controlled via PWM signal,but also serial command.Also gimbal data(like Yaw/Pitch/Roll angle,zoom status etc) can be obtained by sending serial command to the gimbal via its serial port, which is really useful for precise gimbal control and system integration.

Object tracking and geotagging function
2 useful features are available on Sky Eye-30HZ-S.The first one is tracking,which will enable the pilot to track object freely during daytime or night time. The second one is geotagging,that means the gimbal will geotag the gimbal position on video streaming or photo that you currently choose on screen,and GPS coordinate will be displayed on the screen too.

Clean and simple wiring
Sky Eye-30HZ-S provides an outstanding wiring hub design for RC receiver and video output port(AV and HDMI),which makes wiring pretty easily. Also the gimbal offers 2 smart speed modes:FAST speed and LOW speed.Fast speed mode is used for small zooming range,which makes the gimbal control sensitive and quick.LOW speed mode is used for large zoom range,will enable you to target the object more accurately.

Features:
1) 848grams,light weight
2) 1/2.8 inch 2.13MP CMOS SENSOR
3) 30X optical zoom,1080P/60 HDMI output for video downlink
4) 1080P/30 H.264 video recorded for on-board TF card
5) Auto object tracking
6) Geotagging
7) PWM control and serial command control
8) Convenient wiring hub for RC receiver and video output
9) 3-aixs high stabilized gimbal system
10) Adjustable control speed: SLOW speed for large zoom range,accurate.FAST speed for small zoom range,sensitive and quick
