Wise SCADA Tutorial #25 | Symbol Library | Dynamic and Animated SCADA Symbols

Описание: 🔊 Multi-Language Audio Available
This Wise SCADA training video includes multiple audio tracks. Click the Settings (⚙️) icon and select “Audio Track” to choose your preferred language.

In this part of the Wise SCADA training series, we explain how to use the Symbol Library to build dynamic, conditional, and animated SCADA screens.
You will learn how to select industrial symbols, switch between variations, apply tag-based visibility logic, customize colors and styles, and use animation features effectively.

Using commonly used symbols such as pumps, this lesson demonstrates how to visualize default, running, and fault states with tag logic and how to test them during runtime.

📌 What You Will Learn in This Lesson
✅ Wise SCADA Symbol Library overview
✅ Adding symbols and switching variations
✅ Tag-based visibility control
✅ Conditional symbol display logic
✅ Color & style settings (Shaded / Shaded Edge)
✅ Border, background, and padding configuration
✅ Flip and rotation options
✅ Stretch behavior and best practices
✅ Animation modes (Default, Shaded, Invisible, Hollow)
✅ Rotation animation and smoothness
✅ Default, running, and fault state symbols
✅ Priority logic with multiple symbols
✅ Runtime testing with live tag values
✅ Updating symbols via Wizard

🔗 Useful Links
Download Wise SCADA:
https://www.fultek.com.tr/en/scada-so...

⏱️ Chapters
00:00 – Symbol Library Overview
00:13 – Symbol Variations
01:07 – Tag-Based Visibility
01:34 – Fault State Configuration
02:12 – Padding, Flip & Rotation
03:00 – Animation Types
04:14 – Rotation Animation
04:30 – Priority Logic
04:57 – Runtime Testing
05:32 – Wizard Update
