FIREFLIES E07 - 6,900 Lumens - XPL 5000K

Описание: Get the E07 here using discount code: cbrIDgTec - https://www.banggood.com/custlink/3m3...

26% OFF 21700 battery - https://www.banggood.com/custlink/GDD...

23% OFF Fireflies E01 - https://www.banggood.com/custlink/KmK...

About Batteries：

E07 driver is FET+3x7135 , high discharge rate -20A 21700 / 18650 battery can get max turbo brightness
For XPL hi version，-20A discharge rate needed , Such as LS 20A 21700 or 30T or 40T 21700 （18650 VTC6 or 30Q）
For SST20 version, around 20A discharge rate needed, LS 20A 21700 recommended （18650 VTC6 or 30Q）

About Heat Dissipation Structure

E07 has very compact size，however the heat dissipation structure is very well designed.
With 5 deep heat sink trenches and 10mm thick integrated shelf , the light can sustain the crazy 7000 lumens brightness .


About thermal Step down：

E07 is one of the brightest single battery flashlights， It will get hot very quick on high brightness levels.
E07 set the tempreture limit to 50℃ by default. The light will automaticly step down when the body temperature is over 50 degree. The temperature can be configured by users if you read the manual carefully.


About conductive Springs and electrical wires：

The springs used in E07 are made of gold-plated copper alloy ，which have an extreme low internal resistance. The electrical wires are teflon silver-coated 18AWG wire. So E07 has a very well electrical conductive ability to maximize the Lumen output.


About the clip：

The clip is press-fit design. Please daub a little oil onto the clip when installing the clip onto the body, So the body wont get any scratched.


Version type:

7x SST20 4000K FA3 NW CRI95 3800 lumens Turbo
7x SST20 L5 6500K CW / L5 5000K NW 6900 lumens Turbo brightness
7x SST20 L5 DA 5000K CW / L5 5000K NW 6900 lumens Turbo brightnes
7x CREE XPL HI V3 CW 6500K 6900 lumens Turbo brightness
7x CREE XPL HI V3 3A NW 5000K 6900 lumens Turbo brightness 25 000cd
7x CREE XPL HI V2 5A NW 4000K 6200 lumens Turbo brightness 25 000cd
7x Osram KW CSLNM1.TG 6500K 6500 lumens (powered by 40T) ; 60 000cd
Product Description:

Made of 6063 aluminum alloy and 304 stainless steel
Body color: Matt Black , Gun Grey and Desert Yellow
HAIII Anodising Surface Finish
1x 21700 / 18650
25 degree angle TRI lens
98% AR coating glass lens
Digital current regulation on lower brightness
IPX6 waterproof
with Aux leds ; with switch leds
Size: 113mm(L )x 37.5mm(Head) x 26mm(Body)
Net Weight: 125 gram
Accessories: standby O rings ; Stainless Steel clip; Landyard; Gift box


How to operate the light?

Fireflies uses free software distributed under the terms of the GNU Public License version 3

ROT66 Anduril code from toykeeper/flashlight-firmware
