Orientation to the Basic Motor Control Kit

Описание: In this application exercise we'll examine the contents of a kit I use to teach basic motor control. An orientation to and inspection of this kit's contents make a great practical exercise to accompany the contactors, control relays, overloads, and switches in electrically controlled systems lectures, all available at the bigbadtech channel.

If you wish to replicate this kit, here is the part list from automation direct:
BM3RHB-1P6 MMS 1.6A 45MM ROTARY
CWC07-10-30V18 CONTACTOR 7A 3 N.O. PWR POLES 120VAC COIL N.O. AUX MINI SERIES
BFC0-22 AUX CONTACT FRONT MOUNT 2 N.O./2 N.C. FOR MULTI MINI CONTACTORS
RW17-1D3-D012 OVERLOAD RELAY 0.8-1.2A 1 N.O./1 N.C. FOR MULTI MINI CONTACTORS
GCX3320-22 SEL SW 22mm PLAS BLK 2 N.C./2 N.O. MNTND 3-POS KNOB PLAS BEZEL
GCX3131 PB MUSH 22mm PLAS RED N.C. TWST-REL 40mm HEAD PLAS BEZEL
GCX3101 PB FLUSH 22mm PLAS RED N.C. MOM 30mm HEAD PLAS BEZEL
GCX3102 PB FLUSH 22mm PLAS GRN N.O. MOM 30mm HEAD PLAS BEZEL
GCX3103 PB FLUSH 22mm PLAS YEL N.O. MOM 30mm HEAD PLAS BEZEL
GCX1231-120L IND LIGHT METAL 22mm RED 120V LED-ILLUM
GCX1232-120L IND LIGHT METAL 22mm GRN 120V LED-ILLUM
GCX1233-120L IND LIGHT METAL 22mm YEL 120V LED-ILLUM
ECX1030-5 CONTACT BLOCK REPLACEMENT 22mm N.C. FOR GCX & ECX SERIES 5/PK
ECX1040-5 CONTACT BLOCK REPLACEMENT 22mm N.O. FOR GCX & ECX SERIES 5/PK
BIC0 MECHANICAL INTERLOCK FRONT MOUNT FOR MULTI MINI CONTACTORS
ECC0-R WIRING KIT REVERSING FOR MULTI MINI CONTACTORS
