Make 2D from any Rhino mesh - in seconds!

Описание: We all have been in a situation, when we spend hours and hours to create an elegant organic mesh structure. Then comes the time to make crisp and clean diagrams and drawings - but default Make-2D in Rhino doesn't provide a desired result. Waiting for minutes to get the lines from a 3d-geometry and then maybe hours on cleaning the result.
Luckily, we have developed a very simple yet efficient workflow that allows you to turn any mesh into a high-quality 2D-drawing without necessity to clean it or wait for a long time.

Check our new tutorial and please let us know in comments what would you like us to show next!
More videos on mesh modeling in Rhino and Grasshopper:    • Understanding complex geometries in Grassh...

We provide online courses on parametric design tools and accept commissions for projects
Our website - https://ingeneric.org
Parametric design market - https://ingeneric.org/market
Our Instagram -   / in_generic

0:00 - Introduction
1:55 - Preparing geometry in Grasshopper
3:50 - The trick
5:40 - Bringing geometry to Rhino
7:10 - Make 2D settings
9:42 - 2D result
10:10 - Drawing fine-tuning
11:10 - Creating a diagram outline
12:25 - FInal result
