PROBLEM NO 10 SECTIONS OF SOLIDS SOLUTIONS WITH explanation (Engineering Drawing by N.D.BHATT)

Описание: #rakesh_valasa #sections_of_solids #engineering_drawing #10
Problem no.10
A tetrahedron of 65 mm long edges is lying on the H.P. on one of its faces, with an edge perpendicular to the V.P. It is cut by a section plane which is perpendicular to the V.P. so that the true shape of the section is an isosceles triangle of base 50 mm long and altitude 40 mm. find the inclination of the section plane with the H.P. and draw the front view, sectional top view and the true shape of the section.
