MeshWorks Tutorial -- HOW TO EPISODE 5: 2D Mesh Editing
Автор: DEP MeshWorks Europe | Dynas+ Engineering Products
Загружено: 2023-09-14
Просмотров: 617
Описание:
This video takes a detailed look on how to edit a 2D mesh, with a set of tools available.
It covers the topic of the presentation of the MeshWorks philosophy. This includes the modification of the mesh and the insertion of features directly at the FE level. It finish with the projection of nodes to fit on the CAD.
#DEPUSA#MeshWorks#software #tutorial #finiteelementmethod #mesh #simulation #meshing #2d #editing
-------------------------------------------------------------------------------------------
Agenda:
0:00 MeshWorks Philosophy
0:57 Stitch
2:06 Replace Nodes
2:30 Collapse Slivers
3:00 Element Split
3:53 Align Nodes
4:07 Feature Insert
7:02 Project
-------------------------------------------------------------------------------------------
LinkedIn: / depeurope
Web site: https://depeurope.com/en/
