How to use Jedicut to make g-code for a tapered wing tutorial
Автор: rcKeith
Загружено: 2018-06-21
Просмотров: 23614
Описание:
In this video, I show how we can cut a large swept back tapered wing on a 4 Axis hot wire CNC foam cutter. I use Jedicut to generate the g-code. Jedicut is French software and is free. The g-code can be run on my latest USB Foam Cutter as well as LinuxCNC and Mach3.
The first part is the sweep wing trick or hack and Jedicut starts at • How to use Jedicut to make g-code for a ta...
Cutting large swept-back wings can be a challenge on hotwire machines and you can soon run out of travel even on a mild sweep. I show a little hack or trick to get a swept-back wing as big as you need.
If you would like to build a 4 axis hot wire machine then I have a full build tutorial including eBook, plan and part list on my website. https://rckeith.co.uk/hotwire-cnc-foa... Its not as expensive as you might think
This is another g-code generator if you don't want to use JediCut
G-code generator http://swarfer.co.za/rc/wire/index.php
Airfoil Database
http://m-selig.ae.illinois.edu/ads/co...
